High Speed Dry Suspension Filling Machine can be equipped with bottle unscrambler, bottle washing machine and labeling machine to form a complete filling line. Widely used in pharmaceutical, food, chemical and other industries, such as medicinal powder, condiment, milk powder, metal powder, etc.
High Speed Pharmaceutical Powder Bottle Filling Machine
Features
1, Touch screen PLC intelligent control, with functions such as no bottle no filling, no bottle no capping and no bottle stop.
2, Intelligent control of filling volume: the touch screen directly inputs the filling volume, and the filling volume is automatically calibrated. It is extremely convenient to switch between different specifications and adjust the loading volume, and there is no requirement for the level of the operator. Avoid the trouble of traditional test while adjusting.
3, Equipped with a capping correction mechanism, which reduces the tendency of crooked capping in conventional methods and improves the accuracy and efficiency of capping.
4, The fifth-generation capping mechanism of our company is adopted, stainless steel lever-type capping, and the rolling knives are equipped with buffer devices, which can effectively filter the errors of packaging materials (bottles and caps), and have better applicability, and the effect is obviously better than the conventional one.
5, The rolling blade is made of high-hardness stainless die steel, which overcomes the shortcomings of short life and easy rusting of conventional rolling blades.
6, Overload protection and alarm prompt, more safe and reliable.
Technical parameter
| Items | Parameters |
| Production speed | 80-120BPM (adjustable) |
| Filling Range | 5-30g (accuracy ±1% based on 100gr) (may need extra screw) |
| Air source | 0.6～0.8MPa |
| Power supply | 220V/50Hz |
| Total power | 5kw |
| Total weight | 800kg |
| Dimensions | 4000×2000×2200mm |
Contact Qualipak Machinery to know more details!
