The Automatic Capsules Counting Filling Line consists of the bottle feeding machine(bottle turning feeding table or automatic bottle arranging machine), counting filling machine, desiccant inserting machine, aluminum foil induction sealing machine, labeling machine and bottle collecting machine. If you need box packing machine or bag packing machine, we also have many models for choice.
Bottle Unscrambler
Parameters
| Item | Auto bottle unscrambler | Turning table |
| Power supply | Single phase, 220V | |
| Power consumption | 0.25kw | 0.2kw |
| Feeding speed | 20-80 Bottles/minute | 60-80 bottles/min |
| Total Weight | 200kg | 100kg |
| Dimensions | 1200×1150×1300mm | 650 x 650x 1000mm |
| Automation grade | Fully automatic | Need manually put the bottles |
| Function | Bottle arranging and feeding | Bottle feeding and collecting |
Automatic Capsule Counting Filling Machine
Description
Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc. This machine adopts 8 sets imported counting sensor for counting with 8 Guiding Way and two head. The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen operation and PLC Control for convenient running.
Parameters
| Items | Parameters |
| Application | Filled capsule(00-5#)Soft Gelatin capsulechewing gumTabletother solid object under machine range |
| Hopper Volume | 20L |
| Capacity | 20-30bottles(50-100 pcs/bottle)/min |
| Filling Quantity | 2-9999pcs/bottle (adjustable) |
| Bottle Size | Diameter: 30-75mmHeight:40-250mm |
| Counting Size | Thickness: 3-10mmDiameter: 3-22mmLength: 3-30mm |
| Compressed air | 0.6Mpa |
| Machine Weight | 250kg |
| Machine Size L × W × H (mm) | 1360x1300x1700mm |
Details
Automatic Desiccant Inserting Machine
Description
Tablet and capsule are easy to go moist, so it is necessary to put the desiccant into the container to keep medicine away from moisture in order to improve reliability of guarantee period. The machine applies automatic controlling system to take the place of the previous manual operation. The machine can automatically cut the belted desiccant and insert the desiccant bag into the container accurately and speedily. It is available for bottles and pots made of different materials. It features double-lane photoelectric positioning, intelligent feeding length controlling and automatic adjustment of accumulated length error. The electronic controlling system ensures the machine starts when bottles reach working position and stops when bottles are insufficient automatically. The product conforms to the requirements of GMP completely.
Parameters
| Items | Parameters |
| Bottle Size | 20-300ml |
| Output | 40-100bottles/min |
| Power Supply | 220v 60Hz |
| Power | 0.85kw |
| Overall Dimension | 1150*800*1900mm |
Automatic Capping Machine
Description
The screw capper is available for various bottles and its changeover is fast and easy. The machine overthrows conventional means of arranging cap by electromagnetic oscillation but arranges caps pneumatically to avoid noise pollution and reduce electric power consumption. It also provides international brand PLC controls, variable frequency controls and photoelectric controls. The machine is incorporated with the device of arranging and lifting cap and a big capacity of cap hopper, so less cap feeding times reduces labor intensity. Generally operators can grasp fluently. The machine conforms to the requirements of GMP completely.
Parameters
| Items | Parameters |
| Size of bottles | 20-500 ml |
| Output | 50-150 bottles/min |
| Diameter of caps | φ20-65 mm |
| Diameter of bottles | φ20-120 mm |
| Power supply | 220V 60Hz |
| Power | 1.5KW |
| Overall dimensions | 2160*1050*1900 mm |
| Weight | 650KG |
Detail
Automatic Sticker Labeling Machine
HAY200 Round Bottle Labeling Machine
HAS3500 Square/Flat Bottle Labeling Machine
