5L Jerrycan Juice Filling Capping Machine is our viscous material filling capping machine, this machine is suitable for peanut paste,chocolate cream, jam, honey, glue,cosmetics etc. can connect automatic bottle feeding machine and labeling machine or individual use, it’s widely used in the pharmaceutical , chemical and food industries.
5L Jerrycan Juice Filling Capping Machine Line
5L Bottle Juice Filling Machine with Feeding Stirring Hopper
Description
This automatic linear filling machine is designed for juice filling in 5L jerrycan, the juice is with granules in it.
Technical parameter
| Items | Parameters |
| Filling nozzle | 4 |
| Hopper function | Automatic liquid level detection, automatic feeding, stirring, heating |
| Filling volume | Up to 5L (can be customized) |
| Capacity | ABT. 5-20BPM for 5L |
| Air source | 0.6-0.8MPa |
| Power supply | 220V/50Hz, 2.5kw |
| Total Weight | 600kg |
| Dimensions | 2400*1500*1800mm |
Details
– 4 filling nozzles: Filling quantity can be set in touch screen.
– With slide device: the users can adjust the position of filling nozzles freely to fit in different bottle sizes.
– The cylinder is designed and arranged inside the machine, making the machine simple and beautiful.
– With upper hopper: client can choose to add stirring function and/or heating function, suitable for thick liquid or liquid with granules.
– Hopper can be connected with storage tank.
– With automatic liquid level control function, can detect low liquid level and feed the liquid automatically, which saves manpower.
– With waste water flow out interface, which is convenient to discharge the waste water after cleaning.
Automatic Jerrycan Capping Machine with Cap Elevator
Description
This automatic capping machine is suitable for jerrycan capping with screw type ROPP cap. The machine is equipped with an automatic cap feeding machine – cap elevator. Can achieve fully automatic cap arranging, feeding and capping.
Technical parameter
| Items | Parameters |
| Capping head | Claw type |
| Feeding type | cap elevator |
| Capacity | ABT. 1000-2000BPH |
| Air source | 0.6-0.8MPa |
| Power supply | 220V/50Hz, 1kw |
| Total Weight | 400kg |
| Dimensions | 2000*1500*1800mm |
